Description
The
ABB 5SHY5055L0002 3BHE019719R0101 GVC736BE101 is a high-voltage, high-power
gate-commutated thyristor (GCT) module designed for applications in power transmission and industrial drive systems. As part of ABB’s
5SHY series of advanced power semiconductor devices, this module serves as a critical component in voltage source converters (VSCs) for HVDC (high-voltage direct current) transmission, motor drives, and renewable energy inverters. The
5SHY5055L0002 combines the fast switching capabilities of a transistor with the high current-handling capacity of a thyristor, enabling efficient power conversion in large-scale systems.
Engineered for reliability in extreme conditions, the ABB 5SHY5055L0002 features a robust press-pack design with ceramic-insulated terminals, ensuring high thermal conductivity and mechanical stability. Its core functions include precise control of power flow in HVDC grids, dynamic voltage support for renewable energy integration, and motor speed control in industrial applications like rolling mills and cement plants. Positioned as a premium solution for utility-scale power systems, the module enhances grid stability, reduces energy losses, and supports the transition to smarter, more sustainable energy networks. The 5SHY5055L0002 3BHE019719R0101 GVC736BE101 embodies ABB’s leadership in power electronics, delivering unmatched performance in high-stakes applications where reliability and efficiency are non-negotiable.
| Parameter Name |
Parameter Value |
| Product Model |
5SHY5055L0002 3BHE019719R0101 GVC736BE101 |
| Manufacturer |
ABB |
| Product Type |
Gate-Commutated Thyristor (GCT) Module |
| Voltage Rating |
5.5 kV (5500 V) |
| Current Rating (RMS) |
3,000 A |
| Switching Frequency |
Up to 2 kHz |
| Thermal Resistance |
<0.01 K/W |
| Cooling Method |
Forced air or liquid cooling |
| Dimensions (W×H×D) |
200 mm × 300 mm × 100 mm |
| Operating Temperature |
-40°C to +125°C |
| Certification |
IEC 60747-5, IEEE 1709, RoHS |
5SHY5055L0002 3BHE019719R0101 GVC736BE101
High Power Handling and Efficiency: The 5SHY5055L0002 is designed to manage extreme voltage and current levels, making it ideal for HVDC systems that transmit power over long distances. Its low on-state voltage drop reduces power losses, while the gate-commutated design enables faster switching than traditional thyristors, improving overall system efficiency by up to 15%.
Robust Mechanical and Thermal Design: The press-pack construction eliminates soldered joints, enhancing durability in high-vibration environments. The module’s ceramic insulation and advanced heat sink compatibility ensure reliable thermal management, even under continuous full-load operation. This design also supports easy replacement in modular converter systems, minimizing downtime during maintenance.
Precision Control and Grid Stability: By enabling rapid switching and precise current control, the 5SHY5055L0002 supports dynamic reactive power compensation, which is critical for stabilizing grids with high penetration of renewable energy sources. Its compatibility with ABB’s PCU602 control unit allows for real-time monitoring and adjustment of switching parameters, optimizing performance in both steady-state and fault conditions.
Scalability and System Integration: The module is part of ABB’s scalable portfolio of power semiconductors, allowing engineers to design converter systems ranging from tens of megawatts to gigawatt-scale HVDC projects. Its standardized interface ensures seamless integration with ABB’s
HVDC Plus technology and other third-party converters, reducing engineering complexity and project timelines.
5SHY5055L0002 3BHE019719R0101 GVC736BE101
The ABB 5SHY5055L0002 3BHE019719R0101 GVC736BE101 is essential for applications requiring high-power, high-voltage control:
- HVDC Transmission Systems: Used in VSC-HVDC converters to transmit bulk power between grids, connect offshore wind farms, and enable asynchronous grid interconnections. For example, it supports projects like ABB’s Sicily–Mainland Link, where precise power flow control is critical.
- Industrial Drives: Powers large motors in sectors like mining, steel, and paper production, providing reliable speed and torque control for heavy-duty machinery such as conveyor belts and rolling mills.
- Renewable Energy Inverters: Enables efficient conversion of DC power from solar or wind farms to AC for grid integration, addressing the challenges of variable power generation and grid stability.
- Power Quality Management: Supports static var compensators (SVCs) and flexible AC transmission systems (FACTS) to mitigate voltage fluctuations and improve power factor in industrial networks.
By addressing the unique demands of high-power applications, the 5SHY5055L0002 helps customers reduce operational costs, enhance grid resilience, and meet sustainability goals by enabling cleaner, more efficient energy use.
- ABB 5SHY3545L0001: A lower-voltage GCT module (3.5 kV) for medium-power applications like industrial drives and UPS systems.
- ABB 5SHY6065L0001: A higher-voltage variant (6.5 kV) designed for next-generation HVDC and traction systems.
- ABB PCU602 Control Unit: A dedicated controller for precise gate signal generation and module diagnostics.
- ABB BSM300GB120DN2: An IGBT module for lower-power applications, complementary to GCTs in hybrid converter designs.
- ABB UNS3010 Substation Automation System: Integrates with the GCT module for real-time monitoring and protection in HVDC substations.
Pre-installation preparation: Ensure the module is handled with anti-static equipment and mounted in a grounded converter cabinet with adequate cooling infrastructure (e.g., heat sinks, cooling fans). Verify that the mechanical alignment and torque specifications for the press-pack terminals are met to avoid electrical arcing or thermal stress. Connect the gate control signals using shielded cables to minimize interference, and configure the control unit (e.g., PCU602) to match the module’s switching parameters.
Maintenance recommendations: Regularly inspect the module for signs of physical damage or corrosion, particularly in outdoor or high-humidity installations. Use thermal imaging to monitor temperature distribution and ensure cooling systems are operating efficiently. Periodically test the gate drive circuitry for signal integrity and replace any worn-out components, such as cooling fans or thermal interface materials. ABB’s Predictive Maintenance Services can provide advanced diagnostics, including partial discharge testing and lifetime estimation, to optimize maintenance schedules and prevent unexpected failures.
ABB stands behind the 5SHY5055L0002 3BHE019719R0101 GVC736BE101 with a 5-year warranty, reflecting confidence in its durability and performance. ABB’s global service network offers 24/7 support for installation, commissioning, and emergency repairs, with certified technicians available for on-site service. Customers can access advanced diagnostic tools and firmware updates through ABB’s Ability™ digital platform, ensuring the module remains optimized for evolving grid requirements. With rigorous type testing against IEC standards and a proven track record in mission-critical applications, the 5SHY5055L0002 is a trusted choice for power infrastructure projects worldwide.
