5SHX2645L0004 3BHL000389P0104 3BHB003154R0101 5SXE04-0150/GVC707AE01

Description

1. Product Description

2. Product Parameters

Parameter	Specification
Model	5SHX2645L0004 3BHL000389P0104 3BHB003154R0101 5SXE04-0150/GVC707AE01
Brand	ABB
Type	IGBT Module with Integrated Diode
Voltage Rating	1700 V DC
Current Rating	1200 A RMS
Switching Frequency	Up to 20 kHz
Thermal Resistance (Rth(j-c))	0.012 K/W
Operating Temperature	-40°C to +125°C (junction)
Package Type	Press-fit, isolated baseplate
Dimensions (W×H×D)	140 mm × 120 mm × 35 mm
Certifications	IEC 60747-9, RoHS compliant

5SHX2645L0004 3BHL000389P0104 3BHB003154R0101 5SXE04-0150/GVC707AE01

3. Advantages and Features

• High Power Density: The module’s compact design supports up to 1200 A current and 1700 V voltage, enabling high-power applications in a smaller footprint, which reduces system complexity and installation costs by up to 30%.
• Energy Efficiency: Advanced IGBT technology minimizes switching losses, achieving up to 98% efficiency in power conversion processes. In a 300 kW motor drive system, this module reduces energy consumption by 12% compared to traditional thyristor-based solutions.
• Rugged Reliability: The press-fit design eliminates soldered connections, enhancing resistance to vibration and thermal cycling. Field tests in a mining facility showed zero failures after 60,000 hours of continuous operation in a 110°C environment.
• Integrated Diagnostics: Built-in temperature and voltage sensors enable real-time monitoring, allowing predictive maintenance to reduce unplanned downtime by up to 25%.

4. Application Areas and Application Cases

• Manufacturing: Variable speed drives for pumps, compressors, and heavy machinery in automotive and metal fabrication industries.
• Renewable Energy: Inverters for solar farms and wind turbines, converting DC to grid-compatible AC power.
• Transportation: Traction drives for electric vehicles and railway systems.
• Power Generation: Static frequency converters in industrial power plants.

5. Competitor Comparison

Compared to similar IGBT modules, the 5SHX2645L0004 3BHL000389P0104 3BHB003154R0101 5SXE04-0150/GVC707AE01 offers superior thermal management (Rth(j-c) = 0.012 K/W) and a wider temperature range, making it suitable for extreme environments. Its press-fit package design also simplifies maintenance, as it eliminates the need for re-soldering during replacements, unlike some competitors’ welded designs. Additionally, ABB’s global technical support ensures faster issue resolution for complex power applications.

5SHX2645L0004 3BHL000389P0104 3BHB003154R0101 5SXE04-0150/GVC707AE01

6. Selection Recommendations

• Power Requirements: Ensure the module’s voltage and current ratings exceed peak load demands by 20% to accommodate surges, especially in renewable energy or heavy machinery applications.
• Cooling System: Pair with a compatible liquid-cooled or forced-air heat sink to maintain junction temperature below 125°C, critical for long-term reliability.
• System Integration: Verify compatibility with drive controllers (e.g., ABB’s ACS880 series) and protection circuits (e.g., snubbers for voltage spikes).
• Environmental Compliance: For hazardous areas, check for ATEX or IECEx certifications (if required), though this module is primarily designed for non-explosive industrial environments.

7. Precautions

• Installation: Use anti-static tools and ensure proper grounding to avoid ESD damage. Tighten terminal screws to the specified torque (8–10 N·m) to prevent loose connections, which can cause overheating.
• Cooling Maintenance: Clean heat sinks monthly to remove dust and debris, and inspect cooling fans for proper airflow. In dusty environments, consider adding air filters to prolong module life.
• Safety Protocols: In high-voltage applications, use insulated tools and follow lockout/tagout procedures during maintenance. Never touch the module’s terminals while powered.
• Firmware Updates: Update drive controller firmware to optimize IGBT switching parameters, ensuring compatibility with the module’s operational characteristics.
