ABB 3BHL000390P0104 and 5SHX1960L0004 Product Documentation
The
ABB 3BHL000390P0104 (Gate Drive Unit) and 5SHX1960L0004 (IGCT Thyristor Module) are critical components for high-power industrial automation systems. The
3BHL000390P0104 provides precise gate control for ABB’s Integrated Gate-Commutated Thyristor (IGCT) modules, enabling fast switching (≤10 μs) and reliable operation in medium-voltage (MV) applications. The
5SHX1960L0004 is a 4.5 kV/1960 A IGCT module designed for MV drives, static var compensators (SVCs), and high-voltage direct current (HVDC) systems. Together, they deliver low losses, high efficiency, and rugged performance in harsh environments, ensuring seamless integration with ABB’s industrial control platforms (e.g., AC800M, Advant OCS).
| Model |
Type |
Key Specifications |
| 3BHL000390P0104 |
Gate Drive Unit |
– Input: 24 V DC
– Output: 15 V (gate signal)
– Switching Frequency: 10 kHz
– Compatibility: ABB IGCT modules (e.g., 5SHX1960L0004) |
| 5SHX1960L0004 |
IGCT Thyristor Module |
– Rated Voltage: 4.5 kV
– Rated Current: 1960 A (continuous)
– Surge Current: 12,000 A (10 ms)
– Dimensions: 290 mm × 323 mm × 35 mm |
3BHL000390P0104 5SHX1960L0004
- Precision Control: Optimized gate signals reduce switching losses by 15% compared to legacy drivers.
- Fault Tolerance: Built-in overcurrent protection (OCP) and short-circuit detection ensure safe operation.
- Reliability: MTBF > 200,000 hours (ABB testing), with wide temperature support (-40°C to +85°C).
- High Efficiency: Low forward voltage drop (≤1.5 V) minimizes energy waste, achieving 95% system efficiency.
- Rugged Design: Press-pack construction withstands thermal cycling (100,000+ cycles) and short-circuit faults (3× rated current).
- Scalability: Easy series/parallel connection for MV systems (e.g., 10–100 MW drives).
- Energy (HVDC, wind/solar inverters), manufacturing (steel mills, pumps), and utilities (grid stabilization).
A 50 MW MV drive in a Chinese steel plant used 5SHX1960L0004 with 3BHL000390P0104. The solution reduced harmonic distortion by 30%, improved power factor to 0.99, and cut maintenance costs by 40% over 5 years.
| Feature |
ABB 3BHL000390P0104/5SHX1960L0004 |
Market Alternatives |
| Voltage Rating |
4.5 kV (IGCT) |
3.3–4.16 kV (typical) |
| Switching Speed |
10 μs (IGCT) |
15–20 μs (GTOs) |
| Gate Drive Complexity |
Integrated design (no external components) |
Requires separate drivers (adds cost) |
| Warranty |
3 years (IGCT), 2 years (drive) |
1–2 years (industry standard) |
3BHL000390P0104 5SHX1960L0004
- Compatibility:
- Ensure alignment with ABB’s IGCT portfolio (e.g., 5SHX series) and control systems (AC800M).
- Verify voltage/current requirements (e.g., 4.5 kV for HVDC, 1960 A for large drives).
- Environment:
- Use optional IP65 enclosures for dusty/humid environments (3BHL000390P0104).
- Apply forced-air cooling for 5SHX1960L0004 in high-temperature settings (>50°C).
- Budget:
- Balance upfront cost with long-term savings (e.g., 5SHX1960L0004’s efficiency pays back in 24 months).
- 3BHL000390P0104: Follow ABB’s wiring diagrams (shielded cables for gate signals).
- 5SHX1960L0004: Torque mounting screws to 15 N·m (avoid over-tightening); use anti-vibration mounts.
- Clean dust from cooling fins quarterly (5SHX1960L0004).
- Replace gate drive capacitors every 7 years (3BHL000390P0104).
- Disconnect power for 10 minutes before servicing (discharge stored energy in 5SHX1960L0004).
- Use ABB-certified technicians for repairs (compliance with IEC 60747-5-1).
Conclusion
ABB’s 3BHL000390P0104 and 5SHX1960L0004 set the standard for high-power industrial control, combining precision, reliability, and efficiency. Ideal for MV applications, they deliver unmatched performance in critical infrastructure and manufacturing.
