ABB 3ASC25H215E DATX131 is a high-reliability data acquisition and transmission module designed for industrial automation systems. As a core component of ABB’s control solutions, the
3ASC25H215E DATX131 enables precise collection, processing, and transmission of analog and digital signals in complex industrial environments. This module is engineered to support real-time data exchange, making it ideal for applications where accurate and timely information is critical. The
ABB 3ASC25H215E DATX131 features a robust design with advanced signal conditioning capabilities, ensuring stable performance even in harsh conditions such as high noise or fluctuating power supplies. Its compatibility with ABB’s control platforms simplifies system integration, positioning the
3ASC25H215E DATX131 as a key enabler for smart manufacturing and process optimization.
| Parameter |
Specification |
| Signal Types |
Supports analog (4–20 mA, 0–10 V) and digital (TTL/CMOS) |
| Channels |
16 analog input channels, 8 digital input/output channels |
| Resolution |
16-bit analog-to-digital conversion |
| Sampling Rate |
Up to 100 kS/s (analog channels) |
| Communication Interface |
Ethernet (10/100 Mbps), Modbus RTU |
| Power Supply |
24 V DC (±15%) |
| Operating Temperature |
-40°C to +70°C |
| Dimensions |
100 mm x 80 mm x 30 mm |
| Certifications |
CE, FCC, IEC 61000-4-2/3/4 (EMC compliant) |
3ASC25H215E DATX131
The ABB 3ASC25H215E DATX131 excels in high-precision signal acquisition, with its 16-bit resolution ensuring minimal error in data conversion. Its wide temperature range and rugged construction make it suitable for extreme industrial environments, such as steel mills or chemical plants. The module’s real-time data streaming capability via Ethernet allows seamless integration with supervisory control and data acquisition (SCADA) systems, enabling predictive maintenance and remote monitoring. For example, in a water treatment plant, the 3ASC25H215E DATX131 successfully monitored 12 analog sensors (e.g., pH, pressure) with a sampling rate of 50 kS/s, providing operators with instant data to optimize chemical dosing and pump efficiency.
This module is widely used in manufacturing, energy production, water/wastewater management, and process industries. A notable case involves a pharmaceutical company that deployed the ABB 3ASC25H215E DATX131 in its batch processing system to monitor temperature, pressure, and flow rates across 16 reactors. The module’s real-time data transmission enabled precise control of chemical reactions, reducing batch processing time by 20% and improving product consistency through accurate parameter tracking.
Compared to similar data acquisition modules, the 3ASC25H215E DATX131 offers a higher channel density and broader signal type support, reducing the need for multiple hardware components. Its advanced EMC compliance ensures reliable operation in high-noise environments, outperforming alternatives in industrial robustness. Additionally, the module’s plug-and-play compatibility with ABB’s control software streamlines commissioning, saving up to 30% of integration time compared to non-native solutions.
3ASC25H215E DATX131
When selecting the ABB 3ASC25H215E DATX131, consider:
- Signal Requirements: Ensure compatibility with your sensor/actuator signal types (analog/digital).
- Channel Count: Match the module’s input/output channels to your system’s monitoring needs.
- Communication Protocol: Verify support for your network infrastructure (e.g., Ethernet, Modbus).
- Environmental Demands: Confirm suitability for temperature, humidity, and vibration levels in your facility.
- Cabling: Use shielded twisted-pair cables for analog signals to minimize interference.
- Grounding: Properly ground the module to comply with EMC standards and prevent ground loops.
- Firmware Maintenance: Regularly update firmware via ABB’s official tools to access new features and bug fixes.
- Hot-Swap Limitations: Avoid replacing the module while the system is powered to prevent data loss or hardware damage.
