Description
The
ABB 216MB66 HESG324510M1 is a high-reliability
memory module designed for ABB’s industrial control systems, specifically engineered to enhance data storage and processing capabilities in PLCs, HMIs, and distributed control systems (DCS). As part of ABB’s portfolio of automation components, this module serves as a critical upgrade for legacy systems or a foundational element in new installations, enabling seamless integration with ABB’s AC 800M, Advant OCS, and other control platforms. The
216MB66 HESG324510M1 provides 216 MB of high-speed storage, supporting real-time data logging, program execution, and system diagnostics in industrial environments where reliability and data integrity are non-negotiable.
Engineered with rugged industrial-grade components, the ABB 216MB66 HESG324510M1 ensures stable performance in harsh conditions, including high vibration, temperature fluctuations, and electromagnetic interference. Its core functions include expanding the memory capacity of control systems to accommodate complex logic programs, historical trend data, and firmware updates. Positioned as a versatile solution, the module enhances system efficiency by reducing data access latency and supporting multitasking operations, making it ideal for applications requiring high-speed processing and large data storage. The 216MB66 HESG324510M1 embodies ABB’s commitment to delivering robust, future-proof components that enable industrial operators to modernize the control systems while maintaining compatibility with existing infrastructure.
| Parameter Name |
Parameter Value |
| Product Model |
216MB66 HESG324510M1 |
| Manufacturer |
ABB |
| Product Type |
Industrial Memory Module |
| Storage Capacity |
216 MB |
| Memory Type |
Flash memory (non-volatile) |
| Interface |
Parallel bus (compatible with ABB control systems) |
| Data Transfer Rate |
50 MHz |
| Operating Temperature |
-40°C to +85°C |
| Dimensions (W×H×D) |
100 mm × 150 mm × 30 mm |
| Mounting Method |
Direct insertion into control system racks |
| Certification |
CE, UL, IEC 61131-2 |
216MB66 HESG324510M1
High-Density Storage and Performance: The 216MB66 HESG324510M1 offers ample storage for large automation programs, including ladder logic, structured text, and function block diagrams. Its high-speed data transfer rate ensures quick access to critical data, reducing cycle times in real-time control applications. The non-volatile flash memory retains data without battery backup, eliminating maintenance tasks and potential points of failure.
Rugged Industrial Design: Built to withstand the rigors of industrial environments, the module features a reinforced PCB with conformal coating to protect against dust, moisture, and chemical contaminants. Its wide operating temperature range and resistance to shock/vibration (compliant with IEC 60068-2 standards) make it suitable for deployment in harsh settings such as manufacturing floors, power plants, and offshore platforms.
Seamless System Integration: Designed specifically for ABB’s control systems, the 216MB66 HESG324510M1 requires no additional drivers or software configuration, ensuring plug-and-play compatibility. It supports hot-swapping, allowing technicians to replace or upgrade the module without powering down the system, a critical feature for minimizing downtime in 24/7 operations.
Data Integrity and Security: The module incorporates error-correcting code (ECC) to detect and correct random data errors, ensuring data integrity even in high-noise environments. Its secure firmware prevents unauthorized access or tampering, aligning with modern industrial cybersecurity standards and protecting against potential threats.
216MB66 HESG324510M1
The ABB 216MB66 HESG324510M1 is essential for industries requiring reliable data storage and processing in automation systems:
- Manufacturing: Used in PLCs to store complex machine control programs for assembly lines, robotics, and quality control systems, ensuring precise and repeatable operations.
- Energy and Utilities: Supports data logging and trend analysis in DCS systems for power plants, substations, and renewable energy facilities, enabling real-time monitoring of critical parameters like voltage, current, and equipment health.
- Process Industries: Ideal for storing batch recipes, process parameters, and historical data in food and beverage, pharmaceutical, and chemical plants, ensuring compliance with regulatory requirements and traceability.
- Transportation and Logistics: Integrates with control systems for automated 仓储 (AS/RS), conveyor networks, and traffic management systems, optimizing material flow and reducing operational delays.
By addressing the challenges of data storage scalability, environmental resilience, and system compatibility, the 216MB66 HESG324510M1 empowers operators to enhance the performance and longevity of their automation infrastructure.
- ABB 512MB67 HESG324511M1: A higher-capacity variant with 512 MB storage, suitable for large-scale control systems requiring extensive data logging.
- ABB 128MB65 HESG324509M1: A lower-capacity option for simpler applications or legacy systems with limited memory requirements.
- ABB AC 800M CPU (PM866AK01): A control system CPU that pairs with the 216MB66 HESG324510M1 to handle complex automation tasks.
- ABB CI522 Communication Module: Enhances data transfer capabilities when used alongside the memory module in distributed control systems.
- ABB TB521 Terminal Block: A complementary component for securing wiring in control cabinets where the memory module is installed.
Pre-installation preparation: Ensure the control system is powered off and grounded before installing the 216MB66 HESG324510M1. Align the module with the socket in the control rack, applying gentle pressure until it clicks into place. Verify that the module is properly seated to avoid connection issues. No software configuration is required, as the system automatically detects the expanded memory.
Maintenance recommendations: Regularly inspect the module for physical damage or loose connections during routine system checks. While the module requires no periodic maintenance due to its non-volatile design, ensure the control cabinet’s environmental conditions (temperature, humidity, dust levels) remain within specified limits to prolong its lifespan. In the event of a fault, replace the module with a pre-formatted spare to quickly restore system functionality, ensuring the new module is compatible with the control system’s firmware version.
ABB stands behind the 216MB66 HESG324510M1 with a standard 3-year warranty, covering defects in materials and workmanship. ABB’s global technical support team provides 24/7 assistance for troubleshooting and replacement, ensuring minimal disruption to operations. The module’s compliance with international standards and rigorous testing processes reinforce its reliability in industrial applications. Customers can leverage ABB’s extensive network of authorized distributors and service centers for quick turnaround on replacements or upgrades, ensuring the continuity of critical automation systems.
Shanxi Xinyeda International Trading Co., Ltd. is your trusted partner, we provide and other automation spare parts sales and technical support. Please visit our website www.xydcontrol.com or contact us and we will be happy to serve you.
