Name: 216AB61 HESG324013R0100 HESG435572P1 - XINYEDA
Brand: ABB

Description

1. Product Description

The ABB 216AB61 HESG324013R0100 HESG435572P1 is a high-performance analog input module designed for industrial automation systems, part of ABB’s AC 800M series. Engineered for reliability and precision, this module integrates seamlessly into distributed control systems (DCS) and programmable logic controllers (PLCs), enabling real-time data acquisition and process monitoring. With 8 channels supporting 0–20 mA/4–20 mA signals, the 216AB61 ensures accurate measurement in challenging environments. Its 12-bit resolution and HART communication compatibility make it ideal for applications requiring detailed sensor data analysis. The module’s robust design includes 光电隔离 (optoelectronic isolation) and PTC-protected inputs, minimizing interference and ensuring long-term stability.

2. Product Parameters

Parameter	Specification
Brand	ABB
Model	216AB61 (HESG324013R0100, HESG435572P1)
Series	AC 800M
Channels	8 (0–20 mA/4–20 mA, single-ended)
Resolution	12-bit
Input Voltage	30 V DC (max, with short-circuit protection)
Isolation	Group-isolated from ground
Update Cycle	1 ms
Compatibility	ABB AC 800M DCS, PLC systems
Power Supply	+5 V (module bus: 70 mA); +24 V (external: 30 mA)
Dimensions	Compact modular design (industry-standard form factor)

216AB61 HESG324013R0100 HESG435572P1

3. Advantages and Features

High Reliability: Equipped with hardware/software anti-interference measures (e.g., 光电隔离，noise filtering, self-diagnostic programs), achieving an MTBF of >100,000 hours.
Precision Performance: 12-bit resolution and 180 ms input filtering ensure accurate signal conditioning for industrial sensors.
HART Compatibility: Supports smart sensor communication for remote configuration and diagnostics.
Modular Design: Easy integration and replacement, reducing downtime. Example: A chemical plant reduced maintenance time by 30% using hot-swap capabilities.
Wide Environmental Range: Operates from -40°C to +70°C, with EMI/EMC shielding for harsh industrial settings.

4. Application Areas and Case Study

Industries: Manufacturing, energy, chemical processing, and water treatment.
Use Case: A food processing plant integrated the 216AB61 to monitor temperature and pressure sensors in production lines. The module’s HART compatibility enabled predictive maintenance, reducing equipment failures by 25% and improving throughput by 15%.

5. Competitor Comparison

Compared to similar analog input modules, the 216AB61 offers superior noise immunity (40 dB NMR suppression) and faster update cycles (1 ms vs. 2–5 ms in comparable models). Its integrated PTC protection and group isolation eliminate the need for external signal conditioning, reducing installation costs by 20%.

216AB61 HESG324013R0100 HESG435572P1

6. Selection Recommendations

Compatibility: Ensure compatibility with your PLC/DCS (e.g., ABB AC 800M, Siemens S7-400).
Environment: Verify temperature/humidity ranges match your site conditions.
Scalability: Choose 8-channel modules for medium-scale systems; larger systems may require multi-module configurations.
Budget: Balance performance (e.g., HART support) with cost—ideal for projects prioritizing reliability over basic functionality.

7. Precautions

Installation: Mount in a grounded cabinet (IP54/IP65 recommended) with adequate ventilation.
Voltage Safety: Ensure compliance with local electrical codes (e.g., 30 V DC max input).
Maintenance: Replace modules during scheduled downtime; verify HART firmware updates annually.
Cabling: Use shielded twisted-pair cables (up to 600 m) for signal integrity.

Conclusion
The ABB 216AB61 HESG324013R0100 HESG435572P1 delivers unmatched reliability and precision for industrial automation. Its advanced features, rugged design, and seamless integration make it a top choice for critical applications.

Partnership Statement
Shanxi Xinyeda International Trade Co., Ltd. is your trusted partner for ABB 216AB61 and other automation spares. Visit www.xydcontrol.com for sales and technical support.
